Gapless metal oxide arrester with composite coating (hereinafter referred to as arrester) for AC power system is used to limit system overvoltage and protect power transmission and transformation products from overvoltage damage. The arrester is mainly composed of high-voltage terminal, metal oxide resistor, external insulation, low-voltage terminal and lower flange. The external insulation is high temperature vulcanized silicone rubber (HTV), which is injection molded at one time. The low-voltage terminal of the arrester is used to connect the on-line monitor or discharge counter. The high-voltage terminal of the arrester with rated voltage grade of 192kv and above is equipped with a voltage equalizing ring.
Operating environment: minimum temperature: - 35 ℃; Maximum temperature: + 45 ℃; The daily average temperature shall not exceed: + 35 ℃; Monthly average maximum relative humidity: 95% (at 25 ℃); Maximum wind speed: 34 m / S; It can be designed according to the special use conditions of users.
Performance characteristics:
1. The internal structure design is reasonable and the potential distribution is uniform;
2. It has high insulation level and high operation reliability;
3. The external insulation surface has strong hydrophobicity and good pollution resistance;
4. Good nonlinearity and excellent protection level.

交流电力系统用无间隙复合外套金属氧化物避雷器(以下简称避雷器)，用于限制系统过电压，使输变电产品免受过电压损害。避雷器主要由高压端子、金属氧化物电阻片、外绝缘、低压端子、下法兰组成。外绝缘为高温硫化硅橡胶（HTV），一次注射成型。避雷器低压端子用于连接在线监测仪或放电计数器，192kV及以上额定电压等级的避雷器高压端配置均压环。

使用环境条件：最低温度：－35℃；最高温度：＋45℃；日平均温度不超过：＋35℃;月平均最大相对湿度：95%（在25℃）；最大风速：34 m/s；可根据用户特殊使用条件进行针对性设计。

性能特点：
1、内部结构设计合理，电位分布均匀；
2、具有较高的绝缘水平，运行可靠性高；
3、外绝缘表面憎水性强，耐污秽能力好；
4、非线性好，保护水平优异。
